ATMP 50%ZEELCHEM™ 111 · Manufacturer & Supplier
ATMP 50% (amino trimethylene phosphonic acid) is an economical organophosphonate threshold scale inhibitor. At just 1–5 ppm, ZEELCHEM™ 111 blocks calcium carbonate crystal growth in supersaturated water, and it blends well with PAA, PMA and zinc salts in cooling water and oilfield programmes.
ATMP 50% Chemical Identity
| IUPAC name | Nitrilotris(methylenephosphonic acid) |
|---|---|
| Synonyms | ATMP, NTMP, amino trimethylene phosphonic acid |
| Molecular formula | C₃H₁₂NO₉P₃ |
| Molar mass | 299.05 g/mol |
| Phosphonate groups | 3 |
| CAS number | 6419-19-8 |
ATMP 50% Specifications
Typical specification for ZEELCHEM™ 111. Every batch is dispatched with a batch Certificate of Analysis (COA).
| Parameter | Specification |
|---|---|
| Chemical name | Aminotris(methylenephosphonic acid) |
| Chemical formula | C₃H₁₂NO₉P₃ |
| CAS number | 6419-19-8 |
| Active ATMP | 50.0% min |
| Phosphorous acid | ≤ 3.0% max |
| Phosphoric acid | ≤ 0.8% max |
| Iron (Fe) | ≤ 10 ppm max |
| Specific gravity | 1.32 – 1.35 g/cm³ |
Applications & Recommended Dosing
Typical starting doses. Final dosing depends on your water analysis and system conditions; our chemists can help you optimize it.
| Application | Dose |
|---|---|
| Open cooling towers | 1.0 – 10.0 ppm |
| Oilfield waterflooding | 10.0 – 20.0 ppm |
| Industrial cleaners & descalers | 1.0 – 5.0% |
- Open recirculating cooling towers
- Oilfield waterflooding & reinjection
- Industrial cleaners & descalers
- Scale & corrosion blends with zinc
How ATMP 50% Works
Threshold inhibition
Blocks active growth sites on CaCO₃ crystals at sub-stoichiometric doses.
Supersaturation control
Prevents scale even when water is supersaturated with calcium carbonate.
Polymer synergy
Combined with PAA or PMA dispersants it gives stronger overall scale control.
Key Benefits
- Strong threshold scale inhibition at low dose
- Cost-effective phosphonate for cooling water
- Blends with polyacrylic acid, maleic polymers and zinc sulfate
- Chemically stable in recirculating and reinjection lines
- Low acute aquatic toxicity (LC50 > 300 mg/L)
How much ATMP 50% do you need?
Packaging, Storage & Safety
⬢Packaging
- 65 kg carboys
- 250 kg virgin HDPE drums
- 1,250 kg IBC totes
- Bulk tankers
❄Storage & Shelf Life
- Store in acid-proof containers
- Keep in a dry, ventilated area away from direct sunlight
- Shelf life: 24 months in sealed original packaging
⚠Handling & Safety
- Acidic corrosive liquid
- Wear chemical splash goggles, nitrile gloves and a protective apron
- On contact, flush with plenty of water
Always read the Safety Data Sheet (MSDS/SDS) before handling. Pan-India dispatch from Vadodara, Gujarat.
TDS, MSDS & COA for ATMP 50%
Request documents instantly on WhatsApp. ZEEL PRODUCT is ISO 9001:2015, ISO 14001:2015 & ISO 22000:2018 certified.
Safety Data Sheet (MSDS)
16-section GHS-format safety, handling and transport information.
Request MSDS →ATMP 50%: Frequently Asked Questions
What is ATMP and how does it prevent scale?
ATMP is an organophosphonate threshold inhibitor that stops calcium carbonate scale from nucleating at sub-stoichiometric doses.
What is the typical ATMP dosage?
1–10 ppm active in open cooling systems, and 10–20 ppm in oilfield waterflooding.
What are the purity and density of ZEELCHEM™ 111?
At least 50% active ATMP, specific gravity 1.32–1.35 g/cm³, and phosphorous acid at 3% or less.
Can ATMP be blended with other chemicals?
Yes. It blends with polyacrylic acid, maleic polymers and zinc sulfate for combined scale and corrosion control.
What is the temperature limit of ATMP?
It is stable to about 150 °C in normal aqueous solutions. Above 200 °C, HEDP or PMA is recommended.
What is the difference between ATMP and HEDP?
Both are threshold phosphonates. ATMP is a strong, economical carbonate inhibitor, while HEDP adds stronger metal chelation and higher thermal stability.
Is ATMP toxic to aquatic life?
It has very low acute toxicity to fish and aquatic invertebrates (LC50 > 300 mg/L) and is handled safely in standard ETP systems.
What packaging is available?
65 kg carboys, 250 kg virgin HDPE drums, 1,250 kg IBC totes and bulk tankers.
What precautions are needed when handling ATMP?
Wear eye protection, chemical-resistant gloves and a protective apron.
Do you provide COA and MSDS with every batch?
Yes. Every ZEELCHEM™ 111 consignment ships with a batch Certificate of Analysis, and the TDS and 16-section GHS Safety Data Sheet are available on request.
